RESIDENTIAL ALUMINUM FLAGPOLES

Residential Aluminum Flagpoles 2018-11-02T10:37:27+00:00

General Information

Designed primarily for residential use, these poles are also suitable for any application including Apartment Complexes, Restaurants and Recreational Facilities.

The Residential Series flagpoles are designed and manufactured to the highest quality standards.

Standard Fittings Included With Pole

Finial – Ball ornament manufactured from 14 gauge spun aluminum.

Truck Assembly – Cast aluminum, cap-style with screws.

Halyard – Braided polypropylene, equipped with cast nylon clips.

Cleat – Cast aluminum attached to the pole with stainless steel screws.

Foundational Sleeve – Heavy duty, Schedule 40 PVC

Optional Pole Accessories

Collar – Cover that fits around pole and covers ground sleeve

Model Height Above Ground Total Overall Length Butt Diameter Top Diameter Wall Thickness Ball Diameter Recomd. Flag Size Shipping Weight
R15 15′ 17′ 3″ 2″ .125″ 3″ 3′ x 5′ 41 lbs.
R20 20′ 22′ 3″ 2″ .125″ 3″ 3′ x 5′ 51 lbs.
R20A 20′ 22′ 3.5″ 2 3/8″ .125″ 4″ 3′ x 5′ 61 lbs.
R25 25′ 27’6″ 3″ 2″ .125″ 3″ 4′ x 6′ 66 lbs.
R25A 25′ 27’6″ 3.5″ 2 3/8″ .125″ 4″ 4′ x 6′ 76 lbs.
R30 30′ 33′ 4″ 2 3/8″ .125″ 4″ 4′ x 6′ 89 lbs.
R35 35′ 38’6″ 5″ 3″ .125″ 5″ 5′ x 8′ 141 lbs.
Model Satin ($) Clear Anodized ($) Bronze ($) Black ($)
R15 450.00 Call for pricing Call for Pricing Call for Pricing
R20 525.00 * * *
R20A 675.00 * * *
R25 600.00 * * *
R25A 800.00 * * *
R30 880.00 * * *
R35 Call for Price * * *

  * Please call for price and availability.
